9018F
The 9018F is LiuGong Australia’s Swiss arm knife in the latest generation of LiuGong’s F series small excavators. When you need a flexible, compact excavator that can take on different job tasks to suit multiple job site challenges, the 9018F delivers.
Operating Weight: 1,900 kg (cab) / 1,800 kg (canopy)
- We’ve made long shifts easy thanks to our top of the range cab environment. Take your place in our suspension seat that holds, supports and gives you the smoothest ride hour after hour. We’ve also placed our cupholder right where you want it most so you can stay energised throughout the day.
- When space is tight, the neat compact design with short tail swing gets you to work
- Control is everything. Load sensing hydraulics deliver precise and smooth operation for excellent grading performance
- The fuel efficient, low noise and low emission Stage V certified Yanmar 3TNV80F-SSLY engine gives the operator the power to perform
SPECIFICATIONS
Operating weight: 1900 kg
Emission rating : Stage V
Engine manufacturer : Yanmar
Engine model : 3TNV80F-SSLY
Displacement : 1.267 L
Rated power : 13.4 kW (18 hp / 18.2 ps) @ 2,200 rpm
Engine output – net : 12.6 kW (17 hp / 17.1 ps) @ 2,200 rpm
Maximum torque : 63.1~67.4 N·m
Type : Variable displacement piston pump
Maximum flow : 196 L/min (51.8 gal/min)
Cylinders : 3
Fuel tank : 28 L (7.4 gal)
Engine oil : 4.4 L (1.2 gal)
Shoe width : 450 mm (18”)
Arm : 1,070 mm
Boom Length : 1,685 mm
